Feature:
Versatile Use in Workshop Applications
High Power at a Low Price
drilling capacity 25 mm
throat 240 mm
spindle nose-to-foot distance 650 mm
spindle speed (6) 125-2825 rpm
spindle mount MT 3
rigid cast-iron construction
height-adjustable machine head
6 speed steps
rectangular table with T-slots and circumferential coolant groove
| TSB 25 – Bench-mounted Column Drill Press | |
| drilling capacity | 25 mm |
| tapping capacity, steel | M 16 |
| working area | |
| foot set up area (length x width) | 310×320 mm |
| spindle nose-to-foot distance | 650 mm |
| throat | 240 mm |
| vertical head travel | 470 mm |
| column diameter | 95 mm |
| headstock | |
| spindle speed | (6) 125 – 2825 rpm |
| spindle mount | MK 3 / MT 3 |
| quill stroke | 110 mm |
| drive capacity | |
| motor rating main drive | 0,75 kW |
| measures and weights | |
| overall dimensions | 700x410x1560 mm |
| weight | 220 kg |
,
