Model | unit | 618A | M818A | SG200 | SG250 | |
Item | ||||||
Max. width to be ground | ㎜ | 165 | 220 | 165 | 220 | |
Max. length to be ground | ㎜ | 470 | 520 | |||
Max. height to be ground | ㎜ | 350 | ||||
table size (W×L) | ㎜ | 155×460 | 210×450 | 150×460 | 200×520 | |
Permanent magnetic chuck size (Optional) | ㎜ | 150×400 | 200×400 | 150×400 | 200×450 | |
Max. longitudinal travel | ㎜ | 500 | 500 | 500 | 570 | |
Max. cross travel | ㎜ | 185 | 240 | 200 | 250 | |
Max. distance from spindle center to table surface | ㎜ | 450 | ||||
Manual vertical feed | per rev. | ㎜ | 1 | 2 | ||
per. div. | ㎜ | 0.005 | ||||
Grinding wheel | Wheel sizes | ㎜ | 200×13×31.75 | 200×20×31.75 | ||
Speed | r/min | 3450 (60HZ) 、2850 (50HZ) | ||||
Spindle motor power | kW | 1.5 | ||||
standard 1.5 (build in spindle: 1.1kw) | ||||||
Max. table loading (include chuck) | ㎏ | 97 | 128 | 110 | 140 | |
Machine weight | ㎏ | 790 | 920 | 1000 | 1120 | |
Machine size （L×W×H） | cm | 133×109×168 | 133×115×168 | 136×135×171 | 145×139×177 | |
Package size (L×W×H) | cm | 115×137×192 | 115×141×195 | 167×156×193 | 167×170×198 | |
Package size (dismantle table) | cm | 134×112×193 | 140×112×198 | 167×112×193 | 167×112×198 | |
,
