Main configuration list
No. | Name | Key parts | Quantity | Brand |
4.1 | Laser source | 6KW/1000w | 1 | IPG |
4.2 | Laser head | Laser head | 1 | Precitec Procutter 2.0 |
4.3 |
Machine | Machine bed | 1 | heavy plate welding machine body |
Gantry | 1 | Cast Aluminum (Whole) | ||
X、Y gear&rack | 3 | Taiwan YYC | ||
X, Y, Z Rail | 3 | Taiwan Hiwin（X axis 35#） | ||
Ball screw | 1 | Taiwan PMI | ||
pneumatic component | some | Japan SMC、Taiwan AirTAC | ||
Electric Elements | Some | Schneider, France | ||
Servo motor | 4 | Japan, Yaskawa | ||
Reducer | 3 | Japan Shimpo（output flange） | ||
4.4 | Software | Control system | 1 | Cypcut |
4.5 | Cooling | chiller | 1 | Tongfei |
4.6 | Dusk removal system | Separate removal | 4 |
|
4.8 | Loading system | Loading parts | 1 | PLC control system |
Product model | TC-P3015 |
Working area | 3000mm*1500mm |
Max Movement Speed | 140m/min |
Max Acceleration | 1.4G |
Positioning Accuracy | 0.03mm/m |
Repositioning Accuracy | 0.02mm |
minimum linewidth | 0.1mm |
